Tabaco case to Lt. Col S.C. Lynn (OBE) – 10 BD RE

Silver hallmarked presentation tabaco case presented to Lt. Col. S. C. Lynn RE from the Officers of 10 BD Co R.E. 1945. Lt. Col. Lynn served with No 12 Coy at Horsham, Sussex. Also Past President Medal from Brighton & Hove Association of Building Trades Employers.

At the beginning of World War Two, little

preparation had been made for the event of

unexploded bombs or UXB's. Among the men

drawn in by the expansion of "Bomb Committe"

were a considerable number of volunteers.

A majority were simply Royal Engineers who

found that they had become bomb disposers as

the result of routine postings.

The life expectancy of a RE Bomb Disposal officer was just ten weeks at the height of the bombing raids. All BD personnel were allowed to apply for tranfer to another service after 6 months of service in bomb disposal. Till the end of June 1940 BD sections dealt with UXB's by the only means available to them. They would uncover the bomb by cautious excavation, remove or try to remove the fuze locking ring - often using a cold chisel & hammer. Then if the bomb had remained quiescent under such treatment, extract the fuze & gaine.

By June 1940 the first two pieces of bomb disposal equipment became available, these were the Crabtree & Universal Key. The Crabtree was a device like a clamp that attached onto the fuze boss, it depressed the charging-plungers & allowd the charge from the fuze to short-circuit until the condensors were discharged rendering the bomb relatively safe. A piece of string could then be tied around the crabtree enabling the BD engineer to pull the fuze from the fuze pocket at a safe distance. The Universal key was a steel bar which could be slid two adjustable lugs that could be fitted into the key-ways of the locking-ring. By turning the operator unscrewed the ring so the fuze & gaine could be removed.

A third & most valuable appartus was the "Steam-sterilizer", a hole was cut in the bomb casing away from the fuze pocket, & the comparatively inert main filling was emulsified by the injection of steam & drained away.

Royal Engineers Bomb Disposal
The unsung heroes of World War Two

World War Two  - Air Dropped Ordnance

British 1942 Anti-tank mine fuze for the Mk V Anti-tank mine

BD personnel not only had to deal with Luftwaffe fuzes, in late 1944 BD squads were tasked with the dangerious job of disposing of thousands of British Anti-tank mines that had been laid all round the coastline of England on beaches and piers as part of the anti-invasion plans. By late 1944 the threat of invasion had passed so removal of these mines fell down to the men of Bomb Disposal.

Bronze Shovel

This very heavy Bronze Anti-Magnetic Shovel is marked 719 BD, a quick search on the internet suggests this unit never existed. But I found reference held with the Imperial War Museum in London that records an account from a veteran who served with this unit. Please see photo at the top of this page which appears to show one Sapper holding this type of shovel.

WW2 "Camouflet" Carbon Monoxide Detector Kit

Used to detect harmful levels of Carbon Monoxide gas where a bomb had exploded underground often without any form of detection on the surface. A number of Sappers lost their lives by Carbon Monoxide possioning. When excavating a bomb a probe was often used to follow the "soft spot" of a bombs path in the ground. Sometimes this probe could penetrate a "camouflet", allowing carbon monoxide gas under considerable pressure to rush up into the shaft above. One good lungfull of this gas would incapacitate a man & after a few seconds he would be dead. Sometimes several lives could be lost trying to rescue the unfortunate man.

Bronze non-magnetic presentation spade

Awarded to "Josh" Sapper J.W. Potter 4th BD Coy T.C.D. Potter was killed in action on

17th December 1944. He is buried at ISLINGTON CEMETERY & CREMATORIUM. If anyone has any further information on "Josh" I would love to hear from you.

Fuze Locking-ring extractor

WW2 period fuze locking ring extractor (spanner). This example stamped with 15 BD Company which operated in the London area & dealt with a number of UXB's that feel in the grounds of Buckingham Palace.

Bomb Disposal - the early years:

The subject of bomb disposal in World War Two is a very complex & lenghty histroy. Below I will give a very brief outline of the early days of bomb disposal. The subject of unexploded bombs quickly developed into a battle between the scienctists on both sides to find ever more ingenious ways to out do the foe. The men of the Royal Engineers Bomb Disposal were stuck the in middle of this secret war & for many it cost them their lives.

Quilter - fuze extractor

Used like a wrench to unwind damged or stuck fuze locking rings.

"Danger Unexploded Bomb" Poster

"Danger Unexploded Bomb" Enamel Sign

Crabtree Discharger (repro)

A quality reproduction crabtree discharger - if you know of an original available then I would like to hear from you!

Non-magnetic Bronze tools

Variety of tools believed to have been used by Bomb Disposal in defusing parachute mines.

If anyone has further information on these toools I would like to hear from you.

50 kg tail fin blown up by BD

This SC 50 kg tail fin is from a 50 kg bomb that failed to explode at East Hoathly, Sussex. It was detonated by BD personnel in situ, this relic was taken by Bob Fry at the time after the explosion, it was still hot!
